DIN 17100 St37-2 is the most common steel grade in common carbon structural steel.ST37-2 steel plate is used in many applications, combining good welding properties with guaranteed strengths.
DIN 17100 St 37-2 Steel equivalent grade:
St 37-2 steel plate/sheet is in DIN 17100 standard, the material number is 1.0037. The equivalent grade of St 37-2 steel are EN 10025 EN 10025, NFA 35-501 E 24-2, UNI 7070 Fe 360 B, BS 4360 40 A, ASTM A 283 C - A 570 Gr. 33.
St 37-2
DIN 17100
Material #:1.0037 |
Comparison of steel grades
|
|
EN 10025
|
S235JR
|
|
NFA 35-501
|
E 24-2
|
|
UNI 7070
|
Fe 360 B
|
|
BS 4360
|
40 A
|
|
ASTM
|
A 283 C - A 570 Gr. 33
|
Chemical Composition for St37-2 Mild steel (Product Analysis Max%)
| Main chemical elements composition of St37-2 |
| Thickness(mm) |
C |
Si |
Mn |
P |
S |
N |
| T≤16 |
0.21 |
0.60 |
1.70 |
0.065 |
0.065 |
0.010 |
| T>16 |
0.25 |
Mechnical Property for St37-2 Mild steel:
| Thickness (mm) |
| St37-2 |
≤ 16 |
> 16 ≤ 40 |
> 40 ≤ 63 |
> 63 ≤ 80 |
> 80 |
| Yield strength (≥Mpa) |
235 |
225 |
215 |
205 |
195 |
| |
< 3 |
≥ 3 ≤ 100 |
> 100 |
| Tensile strength (Mpa) |
360-510 |
340-470 |
340-470 |
ST37-2 Extra Service: Pretreatment (Shot Blasting, Sand Blast, Painting and Galvanized), Cutting Parts, Sample Service, Third Party inspection, UT Test and Size inspection.
Third Party Inspection for ST37-2: ABS, DNV, BV, GL, CCS, LR, RINA, KR, NK, CE, SGS, IKE, IEI or other quality department.
We also offer St37-2 steel plate in various shapes and sizes. If you have any needs in St37-2 steel plate, please feel free to contact us.
