ASTM A36 steel plate is one of the most widely used carbon structural steels used in the industry.As a kind of carbon structural steel product, its relative products are round rod steel, angle bar, and steel sections such as I-Beams, H-beams, angles, and channels.It can be riveted,bolted or welded in the construction of bridges and buildings,and for general structural purposes.
A36 Steel Plate Specification:
Thickness :1.2mm -600mm
Width :1220mm-4200mm
Length :5000mm-18000mm
A36 Steel Plate Mechanical Properties:
| Yield point, min. Ksi |
up to & incl. 8" thick 36 over 8" thick 32 |
| Tensile strength,Ksi |
58-80 |
| Elongation in 8 in., min., % |
20 |
| Elongation in 2 in., min., % |
23 |
A36 Steel Plate Chemical Composition:
|
Thickness, in
|
All |
To 3⁄4 |
Over |
Over |
Over 5⁄2to4incl. |
Over |
| 3⁄4to3⁄2incl. |
3⁄2to5⁄2incl. |
4 |
| Carbon, max, % |
0.26 |
0.25 |
0.25 |
0.26 |
0.27 |
0.29 |
| Manganese, % |
- |
- |
0.80-1.20 |
0.80-1.20 |
0.85-1.20 |
0.85-1.20 |
| Phosphorus, max, % |
0.04 |
0.04 |
0.04 |
0.04 |
0.04 |
0.04 |
| Sulfur, max, % |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
| Silicon, % |
- |
0.40 |
0.40 |
0.15-0.40 |
0.15-0.40 |
0.15-0.40 |
| Copper, min, % |
0.20 |
0.20 |
0.20 |
0.20 |
0.20 |
0.20 |
A36 is readily welded by all welding processes. As a result, the most common welding methods for A36 are the cheapest and easiest: shielded metal arc welding (SMAW, or stick welding), gas metal arc welding (GMAW, or MIG welding), and oxyacetylene welding. A36 steel is also commonly bolted and riveted in structural applications.
